1. Remove the Handle
Touchless Only Configurations (recommended)
IMPORTANT! Do not install the batteries until instructed. The
sensor will activate when the batteries are installed, making it
difficult to complete the installation process.
NOTE: The steps in this section are recommended, but are optional
for most installations. If your installation will retain the handle, go
to the ″Determine the Bracket Location″ section.
Remove the Handle Components
Turn off the water supply to the toilet.
Flush the toilet to remove most of the water from the tank.
Disconnect the chain from the handle.
If the tank has a canister (shown), reattach the chain to itself near
the canister attachment point.
Remove the handle assembly (the nut on the handle assembly
will most likely loosen clockwise).
IMPORTANT! If your model of toilet has a float attached to the
handle chain, the float must not be removed. The float is critical for
proper flushing performance.
Install the Handle Hole Cover
Chain
Hole Cover
Nut
Flush Valve
Handle
Fill Valve
1216369-2-D 4 Kohler Co.
