Operation
NOTE: The remote control must be charged to operate. The remote
control charges when attached to the docking station.
A – Preset 1: Setting the Presets: While seated, adjust the seat
features to your preferences. Press and hold the preset icon for 3
seconds to save activated features at the current settings. Using
the Presets: While seated, press the preset icon to activate features
at your stored settings. If the preset icon is pressed while the seat
is not occupied, the seat will gradually (approximately 2 minutes)
change to your preset temperature.
B – Preset 2: Same as Preset 1.
C – Front: Activates the front wash feature and adjusts the front
wash water pressure.
D – Rear: Activates the rear wash feature and adjusts the rear
wash water pressure.
E – Oscillate: Activates wand movement forward and backward.
Press the icon a second time to stop movement.
F – Pulsate: Alternates the water flow rate. Press the icon a
second time to stop pulsating flow and return to the previously
selected flow rate.
G – Stop: Stops the front wash, rear wash, or air speed features.
H – Nozzle Backward: Retracts the wand.
I – Nozzle Forward: Extends the wand.
J – Deodorizer: Activates or deactivates the deodorizer.
K – H2O Temp: Changes the water spray temperature from low,
to medium, to high, to OFF.
L – Seat Temp: Changes the seat temperature from low, to
medium, to high, to OFF.
M – Air Temp: Changes the heated air temperature from low, to
medium, to high, to OFF.
N – Air Speed: Changes the heated air speed from low, to
medium, to high.
O – Energy Save: When activated, after 24 hours of inactivity the
power indicator LED changes from green to amber, and the seat
temperature changes to low. After 48 hours of inactivity the
heated seat turns off. Once the seat is activated, the power
indicator LED light will change to green, the temperature changes
to the previous user setting, and the timer restarts the energy
save mode.
1054180-5-H 6 Kohler Co.
