1. Install the Mounting Plate
Position the mounting plate over the mounting holes on the bowl.
Position the washers to rest in the openings of the mounting
plate.
Insert each bolt through the mounting plate and into the
mounting holes.
NOTE: The nut should not be threaded onto the bolt. It will not
tighten by threading it into place.
While holding the bolts in place, push a nut up onto each bolt as
far as possible.
Mounting
Plate
Washer
Nut
Kohler Co. 3 1263904-2-C
