3. Connect the Water Supply
CAUTION: Risk of property damage. Do not push or pull
on the water connection between the seat and the water
supply stop. This will prevent water leakage.
NOTICE: Use care to avoid cross threading or overtightening the
connections. Unless otherwise indicated, use an adjustable wrench to
tighten one-quarter turn past hand-tight.
Connect the T-valve to the seat hose.
If needed, connect the supply hose to the supply stop.
Connect the supply hose to the T-valve.
Confirm the filter is in place. Install if needed.
Install the seat hose to the orange colored inlet.
IMPORTANT! The white cap must be in place on the side opposite
the seat hose.
Connect the T-valve to the water inlet on the toilet tank.
Turn on the water supply.
Supply Hose
Supply
Stop
T-Valve
Hose
Filter
Filter
Or
Kohler Co. 5 1263904-2-C
