Kohler K-682 User Manual

Clean the Inlet Screens
Disconnect the power and turn off the water supply.
Disconnect and remove the removable pipe segment.
Using a screwdriver, remove the inlet clamp screws.
Remove the inlet clamp.
Remove the adapters from the valve inlets.
Gently pull the check valves from the valve inlets.
Remove the screens from the check valves.
Clean the screens to remove any dirt or debris.
Rinse or replace the check valves and screens.
Reassemble the inlet connections.
O-Ring
Screw
Screen
Check Valve
Adapter
Union Connection
Removable Pipe Segment
Inlet Clamp
Kohler Co. 7 1043183-5-B
