1. Install the Supply Piping
Multiple Bodyspray Installations
Route the water supply lines.
If installing more than one bodyspray off the same supply line,
construct a pressure balancing loop. Locate a tee along the loop at
each bodyspray installation location.
Do not strap the pipes at this time.
Single Bodyspray Installations
Route the water supply line.
Install an elbow to the end of the supply pipe at the bodyspray
installation location.
All Installations
Temporarily install a nipple to each tee/elbow. Do not use any
sealant.
Do not strap the pipes at this time.
Pressure
Balancing Loop
Water
Supply
Single Bodyspray InstallationMultiple Bodyspray Installation
Nipple
Nipple
Kohler Co. 3 1043851-2-D
