Installation on Finished Deck or Rim (cont.)
Install Valve Bodies
Thread one mounting nut, flange side up, followed by one fiber
washer and one rubber washer onto each valve body.
Insert the 2–7/8” (7.3cm) long copper tubes between the valve
bodies and the 1/2” tee. Insert the 2–3/8” (6cm) long copper tube
into the top of the tee.
Do not solder the connections at this time.
NOTE: The valve body marked “Cold” must be on the right side
when you are facing the front of the faucet.
Insert the valve bodies through the mounting holes from the bottom
of the deck/rim. Match the copper tube from the tee with the spout
supply tube. Hold in place.
Place a collar with the flange side up, onto each valve body. Thread
the collar down to at least 1” (2.5cm) from the top thread on the
valve body.
Install a threaded sleeve fully onto each valve body.
Thread each collar until it contacts the sleeve.
Tighten the mounting nuts on each valve body from underneath the
deck/rim.
Solder the copper tubes to the valve bodies, tee and spout supply
tube.
Ensure that the cold supply is on the right side.
Solder the hot and cold water tubes to the valve body inlets.
Proceed to Check Operation of Valves.
1017937-2-A 6 Kohler Co.
