SECTION
6A
FUEL
SYSTEMS
AND
GOVERNORS
Outlet
Camshaft
Check
Valve
Fuel
Pump
Lever
Inlet
Diaphragm
Check
Valve
Figure
6A-3.
Mechanical
Fuel
Pump.
Removal
1,
Disconnect
the
fuel
lines
from
the
inlet
and
outlet
fittings
of
pump.
2.
Remove
the
truss
head
nylock
screws,
fuel
pump,
and
gasket.
3.
If
necessary,
remove
the
fittings
from
pump
body.
Repair
Nylon-bodied
fuel
pumps
are
not
serviceable
and
must
be
replaced
when
faulty.
Replacement
pumps
are
available
in
kits
which
include
the
pump
and
mounting
gasket.
Installation
(Refer
to
Figure
6A-4.)
Fittings
«25
yw
Truss
Head
Nylock
Screws
Figure
6A-4.
Installing
Fuel
Pump.
1.
Fittings
-
Apply
a
small
amount
of
Permatex®
Avi-
ation
Perm-A-Gasket
(or
equivalent)
gasoline
re-
sistant
thread
sealant
to
fittings.
Tum
fittings
into
pump
6
full
turns;
continue
tuming
fittings
in
same
direction
until
desired
position
is
reached.
2.
Install
new
gasket,
fuel
pump,
and
truss
head
ny-
Jock
screws.
NOTE:
Make
sure
the
fuel
pump
lever
is
posi-
tioned
above
the
camshaft.
Damage
to
the
fuel
pump,
and
subsequent
severe
engine
damage
could
result
if
the
lever
is
positloned
below
the
camshaft.
Torque
screws
to
40/45
In.
Ib.
3.
Connect
fuel
lines
to
inlet
and
outlet
fittings.
CARBURETOR
This
subsection
covers
the
adjustment,
disassembly,
cleaning,
inspection,
repair,
and
reassembly
of
Kohler-buitt,
side
draft,
adjustable
Jet
carburetors.
n
A
WARNING:
Explosive
Fuell
Gasoline
may
be
present
in
the
carburetor
and
fuel
system.
Gasoline
is
extremely
flammable
and
its
va-
pors
can
explode
if
ignited.
Keep
sparks,
open
flame
and
other
sources
of
ignition
away
from
engine,
Wipe
up
spilled
fuel
immediately.
Adjustment
The
carburetor
is
designed
to
deliver
the
correct
fuel/
air
mixture
to
the
engine
under
all
operating
condi-
tions.
Carburetors
are
set
at
the
factory
and
normally
do
not
need
adjustment.
If
the
engine
exhibits
condi-
tions
like
those
found
in
the
table
on
page
6A.4,
it
may
be
necessary
to
adjust
the
carburetor.
Tuming
the
adjusting
needles
In
(clockwise)
de-
creases
the
supply
of
fuel
to
the
carburetor.
This
gives
a
leaner
fuel/air
mixture.
Turning
the
adjusting
needles
out
(counterclockwise)
increases
the
supply
of
fuel
to
the
carburetor.
This
gives
a
richer
fuel/air
mixture.
Refer
to
Figures
6A-5
and
6A-8.
NOTE:
Incorrect
settings
can
cause
a
fouled
spark
plug,
overheating,
excessive
valve
wear,
and
other
problems.
To
ensure
correct
settings,
make
sure
the
following
adjustment
procedures
are
used.
Make
carburetor
adjustments
after
the
engine
has
warmed.
6A.3
