TP-6905 7/18 23Section 2 Generator Set Operation
tp6809
Genset ---->
System
Next Exercise
HR:MN PM MM/DD/YY
Exercise Freq:
Weekly/Every Other Week
Meas. System:
English
<---- Return
Next Exercise *
HR:MN PM MM/DD/YY
Exercise Freq:
Weekly
Exercise Mode:
Unloaded Cycle
Exercise Mode:
None/Unloaded Full Sp/ Un-
loaded Cycle/Loaded Full SP
Contrast:
50
System Freq:
60 Hz
System Voltage:
240 V
VR Voltage Adj:
240.0V
System Phase:
Single
System Battery:
12 V
See Section 2.5.8, Changing
the Exercise Setting
* If the exerciser has not been set, No Exercise Sch will be displayed.
Figure 2-3 Procedure to Set the Exerciser
To Next Page
