-2-
ROUGHING-IN
Unit: mm
BH
SKU
K-37468T 1200-2000 1850-2000
H
B
800-820-2628
IMPORTANT
800-820-2628
The wall channel for the side panel is delivered to the
door assembly. Remove the panel wall channel before
installing the door, but do not remove the transit blocks.
Before installation check that all components are
correctly supplied.
If any parts are missing please ring the helpline.
PARTS IDENTIFICATIONPARTS IDENTIFICATION
1160469-T01-A
