STEP
20
Install the edge strip to fix the side panel.
Fix the glass and the top frame. Then insert the side
seal into the wall frame.
STEP
19
-9-
STEP
21
Insert the cover seal to the top frame.
STEP
18
Fix the magnetic strips onto the door glass and the
side panel, then fix the side seal onto the door glass.
When the door is closed the magnetic
strips should touch along their length.
STEP
22
Insert the bottom seal to the door glass.
1160469-T01-A
