Function
-Heating and cooling type water
dispenser
Rated
voltage/ frequency
230V~, 60Hz
Heating power (Electric Kettle)
1350W
Water heating capacity 8.0L/ h 50 - 100℃
Thermal insulation Plate
19W
Cooling power
80W
Water cooling capacity 2.0L/ h 5 - 10℃
Ambient temperature 10℃ - 38℃
Unit Dimension (WxDxH)
375x345x1150 mm
Net Weight
15.0 kg
Electric shock
resistance
Class I
Applicable water
quality
Purified water
All parameters related to the product performance are the results under the standard
test, and will change with the different service conditions during the actual use.
4
Specifications
Electrical Schematic Diagram
Heating and cooling-type water dispenser
