SPARE PARTS:
Number
Description
Quantity
Code
1
Upper panel 2AE-TOP
1
819003
2
3x5 Button head screw burnished
17
872443
3
Motor board
1
852521
4
M3 brass nut
2
800056/O
5
M3 toothed washer
4
800041
6
Ground cable
2
800090/E
7
I/O EDU 2AE/TOP board
I/O EDU 2AE/TOP/TA board
1
852525
852525/TA
8
M6x40 Transformer fixing bracket
1
872430/N
9
230V 200VA Transformer
110V 200VA Transformer
1
848009
848009/110
10
EDU 2AE-TOP display board
1
852526
11
EDU 2AE-TOP Front panel
1
819002
12
EDU 2AE-TOP membrane
EDU 2AE-TOP/TA membrane
1
819004
819006
13
M12 5 pins connector + nut
M12 8 pins connector + nut
1
201666/R1
201766/LTA
14
M3 washer h0,5 mm
4
800042
15
Spacer 15mm dest4.8mm
4
890004/T
16
M3 zn-white nut
8
800056
17
Plastic support
4
800016/B
18
Bottom panel
1
819001
19
Flat cable amp 10vie-10cm
1
872438/T
20
Flat cable amp 20vie-24cm
1
819007
21
6.3mm spacer dest6.2mm
4
241003
22
Fuse
2
800619
23
I/O connector 9 pin spacing 3,81
1
800164
24
I/O connector 11 pin spacing 3,81
1
800165
25
I/O connector 14 pin spacing 3,81
1
800166
26
I/O connector 10 pin spacing 3,81
1
800102
27
Filtered plug
1
800718
28
Board support
2
872442
