Kolver mini K1/S User Manual

Vers. 140323 rev
Push UNIT
Push ON/OFF
ON/OFF
9. EXTERNAL TRANSDUCER for miniKe
The MINI KEF and MINI KE/S torque testers consist of a MINI KE torque reader and an external static or
rotary transducer. The static transducer combined with a joint simulator allows you to check the torque
measured by the screwdriver and calibrate it according to your needs. The rotary transducer is the ideal tool
for verifying the real torque applied by the screwdriver directly on the screw (and not on a joint simulator).
Thanks to the modification of the FATC (correction factor) and the SENS (full scale value of the connected
transducer), it is possible to calibrate several external transducers in a single MINI KE reader (see
Programming Menu).
Rotary and non rotary transducers for lower or higher torque ranges available on request.
The minike can read torque up to 500 Nm.
MINI KE READER
Push UNIT
See
“DATE”
See
“FATC”
Push UNIT
Push UNIT
Return to the main
screen
Push ON/OFF
Set date and hour:
Push “UNIT” to set hour.min
(24hours, day.month.year.
At each digit push “ON/OFF” to save or
“CLEAR” to exit.
Push ON/OFF
MANUAL Mode:
Push on “UNIT” and “CLEAR” to modify
the FATC.
Remove the weight and push “ON/OFF” to
save.
