E-10
Meter Monitor Item
Monitoring Item Content of Function Range Normal Value Remark
BDI To display battery state-of-charge 0 - 100(%) 0 - 100%
Battery Voltage To display battery voltage. 30.0 - 60.0 (V) 47.0 - 55.0 (V)
Key ON Time To display cumulative time of key ON state 0 - 99999.9 (h) 0 - 99999.9 (h)
R Motor Operating Hours
To display cumulative time of F/R lever ON state of R
motor.
0 - 99999.9 (h) 0 - 99999.9 (h)
R Motor Actual Operating Hours To display cumulative time of R motor command. 0 - 99999.9 (h) 0 - 99999.9 (h)
R Motor Hour-Meter Reading To display operating hours of R motor on meter panel
0 - 99999.9 (h) 0 - 99999.9 (h)
L Motor Operating Hours
To display cumulative time of F/R lever ON state of L
motor.
0 - 99999.9 (h) 0 - 99999.9 (h)
L Motor Actual Operating Hours To display cumulative time of L motor command. 0 - 99999.9 (h) 0 - 99999.9 (h)
L Motor Hour-Meter Reading
To display operating hours of L motor on meter
panel.
0 - 99999.9 (h) 0 - 99999.9 (h)
Pump Motor Operating Hours
To display cumulative time of lift lever ON state of
pump motor.
0 - 99999.9 (h) 0 - 99999.9 (h)
Pump Motor Actual Operating Hours To display cumulative time of pump motor command.
0 - 99999.9 (h) 0 - 99999.9 (h)
Pump Motor Hour-Meter Reading To display operating hours of pump motor command.
0 - 99999.9 (h) 0 - 99999.9 (h)
R motor hour-meter startup swch state
To display [1] when connecting hour-meter startup
wiring of pump motor.
0/1 -
1: The hour-meter startup switch wiring
is connected.
L motor hour-meter startup swch state
To display [1] when connecting hour-meter startup
wiring of pump motor.
0/1 -
1: The hour-meter startup switch wiring
is connected.
Pump motor hour-meter startup swch state
To display [1] when connecting hour-meter startup
wiring of pump motor.
0/1 -
1: The hour-meter startup switch wiring
is connected.
Electrolyte Level Switch To display [1] when electrolyte level is normal.
0: Low
1: Normal
-
Electrolyte Level Sensor Availability Signal
To display [1] when electrolyte level sensor is
equipped with vehicle.
0: Not available
1: Available
-
Controller Cooling Fan ON/OFF To display [1] when cooling fan is working.
0:OFF
1:ON
-
