Power Supply Controller1 (Hybrid vehicle only)
Monitoring Item Content of Function Range Normal Value Remark
Battery Voltage CH0 U (Up)
0 - 81.4
(V)
39.7 - 69.9
(V)
Battery Voltage CH0 D (Down)
The voltage of battery (the lower) is displayed.
0 - 81.4
(V)
39.7- 69.9
(V)
Battery Voltage CH1 U (Up)
0 - 81.4
(V)
39.7 - 69.9
(V)
Battery Voltage CH1 D (Down)
The voltage of battery (the middle) is displayed.
0 - 81.4
(V)
39.7 - 69.9
(V)
Battery Voltage CH2 U (Up)
0 - 81.4
(V)
39.7 - 69.9
(V)
Battery Voltage CH2 D (Down)
The voltage of battery (the upper) is displayed.
0 - 81.4
(V)
39.7 - 69.9
(V)
Battery Current CH0 U (Up)
-105.9 - 105.7
(A)
-60.0 - 60.0
(A)
+ : Charge
- : Discharge
Battery Current CH0 D (Down)
The current of battery (the lower) is displayed.
-105.9 - 105.7
(A)
-60.0 - 60.0
(A)
+ : Charge
- : Discharge
Battery Current CH1 U (Up)
-105.9 - 105.7
(A)
-60.0 - 60.0
(A)
+ : Charge
- : Discharge
Battery Current CH1 D (Down)
The current of battery (the middle) is displayed.
-105.9 - 105.7
(A)
-60.0 - 60.0
(A)
+ : Charge
- : Discharge
Battery Current CH2 U (Up)
-105.9 - 105.7
(A)
-60.0 - 60.0
(A)
+ : Charge
- : Discharge
Battery Current CH2 D (Down)
The current of battery (the upper) is displayed.
-105.9 - 105.7
(A)
-60.0 - 60.0
(A)
+ : Charge
- : Discharge
Capacitor Voltage The voltage of capacitor is displayed.
0 - 114.9
(V)
0 - 59.9
(V)
System Voltage
The voltage being output from power supply controller is
displayed.
0 - 114.9
(V)
5.1 - 69.9
(V)
Capacitor Load Current The current value of body load is displayed.
-1601.3 - 1598.6
(A)
-1335 - 1332
(A)
+ : Charge
- : Discharge
