Komatsu FD115-7 - Page 71

REMOVAL AND INSTALLATION REMOVAL AND INSTALLATION OF UNIT
EX20 Series 30-7
15–28 Nm
{1.5–3.5 kgm}
157–196 Nm
{16–20 kgm}
15–28 Nm
{1.5–3.5 kgm}
15–28 Nm
{1.5–3.5 kgm}
54–88 Nm
{5.5–9 kgm}
27.5–34.3 Nm
{2.8–3.5 kgm}
8.8–14.7 Nm
{0.9–1.5 kgm}
490–607 Nm
{50–62 kgm}
441–539.5 Nm
{45–55 kgm}
735.5–828.5 Nm
{75–84.5 kgm}
Apply LOCTITE to threads.
15–34.3 Nm
{1.5–3.5 kgm}
59–73.5 Nm
{6–7.5 kgm}
441–539.5 Nm
{45–55 kgm}
Apply LOCTITE to threads.
REMOVAL AND INSTALLATION OF UNIT
