ATTACHMENTS, OPTIONS
MUCK DISCHARGE CONVEYOR
ATTACHMENTS, OPTIONS
MUCK DISCHARGE CONVEYOR
2. Tail pulley bearings (2 places)
CHECK AND ADJUSTMENT OF MUCK DISCHARGE CONVEYOR
WARNING
There is always the danger that you get caught in the revolving parts of the conveyor, while inspecting or cleaning it. Be sure to
stop the engine before starting the work.
IS THE BELT NOT SLACKENED?
CAUTION
Stop the engine first and start to work on the adjusting bolt (1).
If the conveyor belt is slackened, it tends to slips off and does not
perform properly. Adjust the belt tension by turning the adjusting
bolts on the right and left sides of the belt.
6 - 12
