Check that it is at the specified level by referring to “METHOD FOR CHECKING OIL LEVEL IN HYDRAUL-
IC TANK, ADDING OIL (4-46)”.
25.
Check the cover (10) mount for oil leakage.
26.
Install the cover (8) with bolts (7) (4 pieces).
27.
Install the cover (6) with bolts (5) (2 pieces).
28.
Install the cover (2) with bolts (1) (2 pieces).
METHOD FOR REPLACING HYDRAULIC OIL FILTER CARTRIDGE
WARNING
• Immediately after the engine is stopped, its parts and oil are still very hot and may cause burn in-
jury. Wait for the temperature to go down, and then start the work.
• When removing the oil filler cap, the oil may spurt out. Turn it slowly to release the internal pres-
sure, then remove it carefully.
Items to be prepared
• Container to catch the drained oil
• Filter wrench
MAINTENANCE MAINTENANCE PROCEDURE
4-67
