Komatsu PC2000-8 BACKHOE - Page 9

A Maximum 10.7 m 35' 9.1 m 30' 7.6 m 25' 6.1 m 20' 4.6 m 15' 3.0 m 10'
B CfCsCfCsCfCsCfCsCfCsCfCsCfCs
7.6 m *21050 *21050 *31450 *31450
25' *46,400 *46,400 *69,300 *69,300
6.1 m *21950 *21950 *33350 *33350 *38650 *38650 *46700 *46700
20' *48,400 *48,400 *73,500 *73,500 *85,200 *85,200 *102,900 *102,900
4.6 m *23400 *23400 *35400 *35400 *42000 *42000 *52200 *52200
15' *51,500 *51,500 *78,000 *78,000 *92,500 *92,500 *115,000 *115,000
3.0 m *25500 24100 *37150 36050 *44850 *44850 *56550 *56550
10' *56,100 53,100 *81,900 79,400 *98,800 *98,800 *124,700 *124,700
1.5 m *28450 24150 *38300 34650 *46650 44900 *59050 *59050 *61150 *61150
5' *62,700 53,200 *84,400 76,300 *102,900 99,000 *130,100 *130,100 *134,800 *134,800
0 m *29800 25050 *38500 33600 *47150 43450 *59400 58650 *68850 *68850
0' *65,700 55,200 *84,800 74,100 *103,900 95,800 *130,900 129,300 *151,800 *151,800
-1.5 m *30250 27000 *37200 33100 *45950 42750 *57550 *57550 *73500 *73500 *48800 *48800 *33650 *33650
-5' *66,600 59,500 *82,000 73,000 *101,300 94,200 *126,800 *126,800 *162,000 *162,000 *107,500 *107,500 *74,200 *74,200
-3.0 m *30350 *30350 *33700 33200 *42650 *42650 *53300 *53300 *67000 *67000 *68250 *68250 *50150 *50150
-10' *66,900 *66,900 *74,300 73,200 *94,000 *94,000 *117,400 *117,400 *147,700 *147,700 *150,400 *150,400 *110,600 *110,600
-4.6 m *29750 *29750 *36050 *36050 *45850 *45850 *57200 *57200 *70850 *70850 *69500 *69500
-15' *65,500 *65,500 *79,400 *79,400 *101,100 *101,100 *126,000 *126,000 *156,200 *156,200 *153,200 *153,200
-6.1 m *27000 *27000 *33150 *33150 *42200 *42200 *50800 *50800
-20' *59,500 *59,500 *73,100 *73,100 *93,000 *93,000 *111,900 *111,900
16
17
LIFTING CAPACITY
LOADING SHOVEL WORKING RANGE
LOADING SHOVEL DIMENSIONS
PC2000-8
Equipment:
● Boom: 8.7 m 28'7"
● Arm: 3.9 m 12'10"
● Bucket: 12.0 m
3
15.7 yd
3
● Bucket weight: 9700 kg 21,380 lb
● Track shoe width: 810 mm 32"
A: Reach from swing center
B: Bucket hook height
C: Lifting capacity
Cf: Rating over front
Cs: Rating over side
: Rating at maximum reach
)
*
+
PC2000-8
Equipment:
● Boom: 8.7 m 28'7"
● Arm: 3.9 m 12'10"
● Bucket: 12.0 m
3
15.7 yd
3
● Bucket weight: 9700 kg 21,380 lb
● Track shoe width: 810 mm 32"
A: Reach from swing center
B: Bucket hook height
C: Lifting capacity
Cf: Rating over front
Cs: Rating over side
: Rating at maximum reach
4600
5410
5650
810 32"
2095
6'10"
5880
R=5980
23
0.9"
5780
7445
13075
8180
4635
5970
6240
15'1"
17'9"
18'6"
19'4"
42'11"
R=19'7"
19'0"
24'5"
20'6"
825
2'8"
6605
7030
15'3"
26'10"
19'7"
21'8"
23'1"
7435
24'5"
7490
310
24'7"
12.2"
Type of bucket Bottom dump
Capacity–heaped 11.0 m
3
14.4 yd
3
A Max. cutting height 14450 mm 47'5"
B Max. dumping height 9665 mm 31'9"
C Max. digging depth 3190 mm 10'6"
D Max. digging reach 13170 mm 43'3"
E Max. digging reach at ground level 11940 mm 39'2"
F Level crowding distance 4850 mm 15'11"
G Min. crowd distance 7090 mm 23'3"
Bucket digging force
721 kN
73500 kgf / 162,040 lb
Arm crowd force
755 kN
77000 kgf / 169,750 lb
Working Range
Type of bucket Bottom dump
Capacity–heaped 11.0 m
3
14.4 yd
3
Width (with side shrouds) 3220 mm 127"
Weight 14400 kg 31,750 lb
Tooth system XS145
No. of bucket teeth 6
Max. material density 1.8 t / m
3
3000 lb / yd
3
F
E
D
G
B
A
C
"
!



!
"
#
$
%
&
'



!
"
#
 &' %$#
"!  !"
* Load is limited by hydraulic capacity rather than tipping. Ratings are based on SAE standard No. J/ISO10567. Rated loads do not exceed 87% of hydraulic lift capacity or 75% of tipping load.
Unit: kg lb
* Load is limited by hydraulic capacity rather than tipping. Ratings are based on SAE standard No. J/ISO10567. Rated loads do not exceed 87% of hydraulic lift capacity or 75% of tipping load.
Unit: kg lb
A Maximum 10.7 m 35' 9.1 m 30' 7.6 m 25' 6.1 m 20' 4.6 m 15' 3.0 m 10'
B CfCsCfCsCfCsCfCsCfCsCfCsCfCs
7.6 m *23900 *23900 *36150 *36150
25' *52,700 *52,700 *79,600 *79,600
6.1 m *24850 *24850 *38350 *38350 *44150 *44150 *52950 *52950
20' *54,800 *54,800 *84,500 *84,500 *97,300 *97,300 *116,700 *116,700
4.6 m *26450 24800 *40700 37700 *48000 *48000 *59350 *59350
15' *58,200 54,700 *89,700 83,100 *105,800 *105,800 *130,800 *130,800
3.0 m *28700 24100 *42800 36050 *51300 47050 *64450 63650
10' *63,200 53,100 *94,300 79,400 *113,100 103,700 *142,000 140,300
1.5 m *31950 24150 *44150 34650 *53500 44900 *67350 60500 *62850 *62850
5' *70,400 53,200 *97,300 76,300 *117,900 99,000 *148,500 133,400 *138,600 *138,600
0 m *34100 25050 *44400 33600 *54150 43450 *67900 58650 *62450 *62450
0' *75,200 55,200 *97,900 74,100 *119,400 95,800 *149,600 129,300 *137,600 *137,600
-1.5 m *35300 27000 *43100 33100 *52900 42750 *65950 57850 *62950 *62950 *54150 *54150 *37650 *37650
-5' *77,800 59,500 *95,000 73,000 *116,600 94,200 *145,300 127,500 *138,800 *138,800 *119,300 *119,300 *83,000 *83,000
-3.0 m *35550 30600 *39250 33200 *49300 42700 *61300 57500 *64650 *64650 *61500 *61500 *55650 *55650
-10' *78,300 67,400 *86,500 73,200 *108,600 94,100 *135,100 127,800 *142,500 *142,500 *135,600 *135,600 *122,700 *122,700
-4.6 m *34950 *34950 *42000 *42000 *53100 *53100 *66000 *66000 *62200 *62200 *62000 *62000
-15' *77,000 *77,000 *92,600 *92,600 *117,100 *117,100 *145,500 *145,500 *137,100 *137,100 *136,600 *136,600
-6.1 m *32150 *32150 *39150 *39150 *49500 *49500 *59650 *59650
-20' *70,800 *70,800 *86,200 *86,200 *109,100 *109,100 *131,500 *131,500
Heavy Lift Off
Heavy Lift On
Unit: mm ft in
)
*
+
LOADING SHOVEL BUCKET
