EXPLANATION OF COMPONENTS
When rotary switch (A) of this switch (14) is turned, the front wiper
will move.
If push button (B) is pressed, washer liquid will be sprayed out onto
the front glass while the button is being pressed.
Position(a): (OFF) stop
Position(b): (INT)Intermittent wiper
Position(c): Low-speed wiper
Position(d): High-speed wiper
When lever (C) of this switch (15) is turned, the rear wiper will
move.
Position (a): Washer liquid is sprayed out
Position (b): OFF
Position (c): Wiper is operated
Position (d): Washer liquid is sprayed out, wiper is operated
This is used to light cigarettes.
After cigarette lighter (16) is pushed in, it will return to its original
position after a few seconds, then you may pull it out and light a
cigarette.
The switch (17) is used to turn the room lamp ON and OFF.
Position (a): OFF
Position (b): Lights up when the cab door opens
Position (c): Lights up
The room lamp lights up even when the main switch is OFF, so
when leaving the operator's compartment, turn the switch to
position (a) (OFF) or (b).
When operating with the cab door fully open, set the switch to
position (a) (OFF).
