Set acceleration and deceleration ramp time values. Acceleration and deceleration ramp time values
for DynADrive 022 can be found in table 7. The corresponding value for DynA45 006 must be set to
parameters P1.7 and P1.8. The original value for the Acceleration and deceleration ramp time can be
found from the original electrical drawings. Default value for trolley acceleration time is 3,5s and bridge
acceleration time 4,5s.
Reducing of the acceleration or deceleration ramp time from the value of the original
delivery is not allowed.
Table 7. Acceleration and deceleration ramp times
DynADrive 022 Acceleration and
deceleration
Ramp Time (s)
Switch S3
-1 -2 -3 -4
0 0 0 0 2,5
0 0 0 1 3,5
0 0 1 0 3
0 0 1 1 5
0 1 0 0 2
0 1 0 1 8
0 1 1 0 1
0 1 1 1 7,5
1 0 0 0 1,5
1 0 0 1 4
1 0 1 0 7
1 0 1 1 6,5
1 1 0 0 4,5
1 1 0 1 6
1 1 1 0 5,5
1 1 1 1 0,5
4
At the DynA45 006 frequency converter; Set P1.9=drive selection, to value 1=travel or 2=travel
compact brake motor.
020145en / Revision D / 2015-04-29
23/31
