5
Package contents
IR
Remote control Batteries AV cable Manual
RS232 cable External power supply
Rear Panel
• This picture is for reference only.
CONNECT TO TVSET HDMI INPUT
CONNECT TO THE POWER SUPPLY
CONNECT TO REMOVABLE DEVICE
CONNECT TO INFRARED RECEIVER
CONNECT TO A PC FOR S/W UPGRADE
LNB IN: CONNECT TO LNB
