SETTING UP YOUR OVEN
Remove the oven and all materials from the carton and oven cavity. Your oven comes with the fol-
lowing
ACCESSORIES:
Names of Oven Parts and Accessories
1 Glass tray
1 Turntable ring assembly
1 Instruction Manual
A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
TURNTABLE INSTALLATION
a. Never place the glass tray upside down.
The glass tray should never be restricted.
b. Both glass tray and turntable ring assembly
must always be used during cooking.
c. All food and containers of food
are always placed on the glass tray for cooking.
d. If glass tray or turntable ring assembly
cracks or breaks, contact an authorized
service center.
Turntable ring assembly
Turntable shaft
Glass tray
Hub (underside)
