17 18
If your child tries to open the ISOFIX buttons or the red release button,
stop immediately . Check whether the child safety seat is correctly
fastened and ensure that your child is correctly secured. Explain to your
child the dangers associated with their actions.
DANGER!
Once the child reaches a weight of 15kg, the 5-point safety
harness should be stored away and the child should be secured
with the vehicle belt.
5. STORE 5POINT HARNESS
5.1
Open the harness buckle (4.2) as shown. Remove seat reducer (15) and
c
rotch pad (8).
5.2
5.4
Loosen shoulder straps (6) .
Open seat cover (4).
Hide shoulder straps (6) and buckle tongues (16) under the cover and
hide the harness buckle
(7) to the storage.
Reattach the 5-point harness:
Follow the steps for <store 5-point harness> in reverse order.
When your child's weight exceed 8kg, remove the triangle pad.
When your child's weight exceed 12kg, remove the seat reducer.
WARNING!
5.3
Tear o the velcro and remove the shoulder pads (5).
6. REARWARD FACING 013KG INSTALLATION
Install the child safety seat with BELT
1. Facing backwards (against the direction of travel) 0-18kg: Do not use on passenger
seats with an active front airbag!
2. Facing forwards (in the direction of travel) 9-36kg: If there is a passenger airbag:
Slide the passenger seat well backwards and follow
7. REARWARD FACING 018KG INSTALLATION
7.1
7.2
Pull out the top tether,by pressing the top tether adjuster (20) button.
Pull the top tether long enough to hang the top tether clip
(21) on the xed point, which on the back of the vehicle
seat, the position of the xed point are shown in the picture(one of the
A/B/C positions).
Install the child safety seat with ISOFIX(refer to page14) (1.2)
(1.3).
Install the child safety seat with ISOFIX + TOP TETHER
6.2
Tighten the vehicle belt in the direction of arrow as shown, adjust the
lap belt rst, then the diagonal belt, which must pass between the
headrest and the backrest. Ensure the vehicle belt is not twisted.
To make sure that the vehicle seat has been installed correctly, please
shake it before use.If shaking or loosening is found, you must
retighten the vehicle belt until the safety seat is stable.
The vehicle belt must not be twisted after installation.
WARNING!
TIP! When the child safety seat is installed in rearward facing, the path
of the lap belt has the same blue guide on the cloth cover.
6.1
Pull out the vechile belt and lock into the vechile seat buckle, with the
diagonal belt bypassess the rear of the seat.Remain the diagonal belt in
same place and the upper part goes through the gap between headrest
and backrest. Open the harness buckle with the lap belt goes between
the seat reducer(15) and backrest.
