15 16
TIP! When installed in forward facing position with belt or belt+ISOFIX
(9-18kg), function of rotation may be restricted.
Press the 360° rotation adjuster (12) with thumb , rotate the seat shell.
2.2
2.1
Rotate the seat shell so it is facing either forwards or backwards,
depending on the weight of your child, until it engages with a
clicking sound.
3. SEAT ANGLE
The seat shell of the 946 CRS can be used in 4 dierent reclined
positions facing forwards and in fifth level position facing
backwards:
It can be adjusted to 4 positions for forward facing use.
When the seat is in the position of fourth level, rotate the seat to the rearward
direction, and the seat can be adjusted to fth level.
3.1
Pull the recline handle (13) up , then the seat can be adjusted.
3.2
0-18kg: rearward facing installation, use fth level.
3.3
9-18kg: forward facing installation, use rst level to fourth level.
15-36kg: forward facing installation, use rst level.
4. PUT THE CHILD IN
Loosen the shoulder straps (6) by pressing the adjustment botton (9)
and pull both shoulder straps forwards, loosen it as much as possible.
4.1
Press red release button (17) to open the harness buckle
(7). Place child in child safety seat.
4.2
When the seat is rotated to 90°, the user can place the child in this
position, but he/she can not use this angle during driving.
DANGER!
WARNING! Before each car journey, in order to ensure your child’s safety, make sure
that····
The child safety seat is fastened in the ISOFIX fastening points (2)
on both sides with the ISOFIX locking arms (22) and both ISOFIX buttons (23) are
fully green;
The child safety seat is securely fastened;
The harness of the child safety seat is tted snugly to the child’s body without
being constricting and should not be twisted;
The shoulder straps (6) are correctly adjusted and the straps are
not twisted;
•
•
•
•
The shoulder pads (5) are in the correct position on your child’s body;
•
The front airbag is deactivated if you are using the child safety seat facing forwards
on the passenger seat;
•
The child safety seat is facing in the right direction for your child’s age/weight;
•
The buckle tongues (16) are inserted into the harness buckle (7).
•
Bring both buckle tongues (16) together. Lock buckle tongues in harness
buckle (7), until they engage with a clicking sound.
4.3
Pull the headrest height adjuster (18), select the correct height of the
headrest (3) and engage it in position that ts your child by releasing
the adjuster.
4.4
Adjust the headrest (3) to proper position. Make sure the distance
between child's shoulder and the bottom of the headrest is lower than
one nger.
4.5
Pull the adjustment strap (10) until the strap lies at and snug on your
child's body.Make sure that the shoulder straps slightly higher or equal
to child's shoulders.
4.6
To Next Page
