308108
• Hook-up of 400V 3~ - 16A
Before connecting the appliance, check the rating
of fuses in your home. If the power mains in your
home allow such option, we recommend a 2-phase
connection to decrease the electric load.
Check that the cabinet and the cut-out meet the dimension and
ventilation requirement
Threat the sawn ends of wooden or synthetic worktops with
sealing varnish if necessary, to prevent moisture causing the
worktop to swell.
Lay the hob upside down on the worktop.
Fit the connecting cable to the appliance in compliance with
requirements.
Remove the protective layer from the sealing tape and apply
the tape in the groove of the aluminium profi le or on the edge
of the glass plate. Do not stick tape round the corners, but cut 4
separate pieces to seal the corners well.
Building in
21
