Strictly follow the installation
and use guidelines provided in
this instruction, otherwise we
may not honour your warranty
rights.
The device must not be installed
in a place that is exposed to
frost.
Hot water cylinder is a device for heating and storing the water. It’s suitable for co-operation with low-temperature
heating boilers. The main element of device is vitreous enamel coated steel tank.
• The WZ cylinder (container) – is equipped with pipe connectors for external connection e.g. to the coil of solid fuel
cooker.
• The WW cylinder (with a heating coil) – water is heated by build-in heating coil fed by a central heating boiler.
• The WB cylinder – is equipped with a heating coil and extra connectors for external connection e.g. to the coil of
solid fuel cooker.
• The WP cylinder (with a water jacket) – domestic water is heated indirectly by a circulating water in external jacket.
The device is suitable for domestic hot water heating in residential buildings, municipal dwellings, sanitary rooms
etc. The unit is designed for horizontal installation only. An immersion heater with temperature controller can be
installed for each unit. The immersion heater need to be installed in place of plug 1½’’ [16] (fig.2 abcd).
Product description
Technical data
Domestic hot water cylinder
WZ
-80
WW
-80
WB
-80
WZ
-100
WW
-100
WB
-100
WZ
-120
WW
-120
WB
-120
WZ
-140
WW
-140
WB
-140
WP
-100
WP
-120
WP
-140
Storage capacity l 80 100 120 140 100 120 140
Rated pressure
tank
MPa
0,6 0,6 0,6 0,6 0,6
coil 0,6 0,6 0,6 0,6
jacket 0,15
Rated temperature °C 80 80 80 80 80
Heat transfer surface area m
2
0,3 0,3 0,4 0,4 0,7 0,93 1,0
Rated power (cylinder) 80/15/45°C* kW 9,5 9,5 11,4 11,4 19,3 25,2 26,8
Efficiency 80/15/45°C* l/h 235 235 295 295 405 526 567
Weight kg 24 26,5 27 28,5 31 31,5 33 36 36,5 36 39 39,5 38 45 49
Dimensions
(fig.2)
diameter mm 480 510
A
mm
485 690 860 930 460 628 700
B 690 858 930
C 920 1125 1295 1365 1085 1255 1325
Magnesium anode 3/4" mm 420 510 420 510
Following parameters: *80/15/45 C – heating water temp./ feed water temp./ domestic water temp. Flow rate of heating water through the coil – 2,67 m
3
/h.
