Replacement Parts List
EF5109
Item# Part Descripition Part Number
1 Log Set VL050-01A
2 Fan/Heater Assembly NFHTX186/VB17-000
3 Synchronization Motor-120Volt AC w/Terminal VL051-01
4 Cord Power 14/3 HPN w/Terminal NFHL008-A
5 ON/OFF Switch PF06-0401-A
6 Heater Control (Thermostat) VL053-01
7 Heater Control Knob NFHL012
8 Flame Generator Assembly/Firewood Glisten Paper VL205-B
9 Light Bulb Socket w/Wiring Assembly VL054-01
10 Screen EL008-01
11 Top Panel EL040-01(B)-O
12 Side Panel (Right/Left) EL015-06-O
13 Left Lower Panel/Right Lower Panel EL012-06 A-O/ EL012-06 B-O
14 Door EL013-01B
15 Brass Knob EL013-01A
16 Back Panel EL019-01
17 Base EL018-06RA-O
18 Upper Decorating Frame EL010-01O
19 Upper Decorating Wire EL011-01
20 Upper (Mid) Louver VL017(EL003-01)
21 Base Plate ( Not Shown) VL091-01
22 Driver Wheel 1/ Driverwheel 2 VL005-05A/VL005-03A
23 Switch Mount Panel ( Not Shown) VL004-01F
24 Bracket ( Not Shown) VCL028-01
25 Pilot Light Bulb Socket w/Wiring Assembly VL075-01
12
