SERVICE INSTRUCTIONS
CLEARANCE TO COMBUSTIBLES
ELECTRICAL CONNECTION
15 AMP, 120 Volt,60Hz circuit with a properly grounded
outlet is required. Preferably, the stove will be on a
dedicated circuit. Other appliances on the same circuit
may cause the circuit breaker to trip or the fuse to blo
when the heater is on operation. The unit comes standard
with a 6’ (1828mm) long three wire cord exiting from the
rear of the fireplace. Plan the installation to avoid the use
of an extension cord. If an extention cord must be used, it
must be a minumum 16 AWG three wire with grounding
type plug connector and rated no less than 1900 Watts.
Back………………0”/0mm
Sides……………..0”/0mm
Floor……………..0”/0mm
Top……………….24”/610mm
WARNING: Electrical outlet wiring
must comply with local building
codes and all other applicable
regulations to reduce the risk o
fire, electrical shock and injury.
WARNING: Do not use this
fireplace if any part of it has been
under water. Immediately call a
qualified service technician to
inspect the fireplace and replace
any part of the electrical system i
necessary.
ELECTRICAL SPECIFICATIONS
Voltage………………120 VAC/60Hz
Total Amps…………..11.3 Amps
Total Watts…………..1345 Watts
Heater Ratings………1200 Watts
WARNING: Disconnect powe
maintenance or cleaning to
reduce the risk of fire, electrical
shock or personal injury
REPLACING LIGHT BULBS
This fireplace uses two clear 120 Volt, 60 Watt, E-12
socket base light bulbs (small base, chandelier candle
type).The 60 Watt bulbs are located under the log
set/ember bed. For convenience, if one of the bulbs
burns out, it may be a good idea to replace both of the
light bulbs.
1. Turn off power to the unit by unplugging the powe
cord.
2. Let fireplace cool if it has been operating.
3. Remove the two fixing self-tapping screws on the
screen. Pull the screen upward a little bit, and then
out.
4. Remove the screws that secure the log set in
position.
5. Examine the bulbs to determine which bulbs need to
be replaced.
6. While holding the socket, unscrew the defective
bulb(s).
WARNING: Do not exceed 60
Watts per bulb. Use of higher
rated bulbs may result in a fire
causing property damage and
personal injury.
3
7. Install the new light bulb(s) by holding the socket
and screwing them.
8. Reinstall the log set and screen. Follow the
above procedure in reverse order.
9. The diameter of the pilot light bulb is 5mm. If the
pilot light bulb need to be replaced, follow steps
1,2,3,4 above. Then use the pilot light bulb
socket
w/wiring assembly replace the primar
pilot part, and connect wires according to
primary connection . Then follow step 8 above.
