Alexander 12’X14’ assembly manual
Upward View
page 15
Parts Required:
K14 x1
1#
x2
K14
K4
1#
1#
Step 12: Connect Outside Roof Connctor
K14
Connect Outside Roof Connctor (Part K14) to inside roof (Part K4) using screw 1#
as shown in the diagram.
