Kozyard Alexander - Gazebo Assembly Steps; Step 1: Set Up Poles

Alexander 12’x14’ assembly manual
page 4
A x4
L x4
1#
x12
A
L
1#
1#
1#
Parts Required:
X4
A
L
X12
3 inches
3/8
inches
M6
(Not included)
1. Set up Poles (Part A) with Stand Plates (Part L) using screws 1# as shown
in the diagram.
Step 1: Set up Poles
Reference for anchoring gazebo:
• If the ground is concrete and its depth is over 3 inches, you can purchase 3/8"
diameter x 3" length sleeve anchors.
• Only anchor after finishing all the assembly.
Attention: After assembly, we strongly recommend anchoring the gazebo to your deck or concrete as
shown above. Damage resulting from wind or improper anchoring is not covered under warranty.
