Table of Content
1 General points 4
1.1 About the documentation 4
1.2 Manufacturer´s address 4
1.3 Intended use 4
2 Safety 6
2.1 Safety instructions and symbols 6
2.2 Staff qualification and training 6
2.3 General safety instructions 6
2.4 Hazard statements 7
3 Device description 10
3.1 General 10
3.2 Flow direction 11
3.3 Basic construction 11
3.4 Dimensions 12
3.4.1 SPV 10 (EN-GJL-300) 12
3.4.2 SPV 10 (EN-GJS-400-15) 13
3.4.3 SPVF 20 - 80 14
3.4.4 SPVF 20 - 80 Table 15
3.4.5 SPVF 50 - 80 (EN-GJS-400-15) 16
3.4.6 SPVF 50 - 80 Tabelle (EN-GJS-400-15) 17
3.5 Types of seals 17
3.6 Type key SPV / SPVF 10-80 18
4 Technical data 19
4.1 General characteristics 19
4.2 Hydraulic specifications 19
4.3 Overview materials 20
4.4 pE-Q characteristic curves (at 34 mm²/s) 21
5 Transport and storage 22
5.1 Transport damage 22
5.2 Transport 22
5.3 Corrosion protection 22
