Always switch off the power to each device before connecting it to your
102xl. After connecting your 102xl, connect its power and then switch
on the power to each device.
To connect up to two balanced audio sources to the 102xl 2 Channel Audio Mixer,
as the example in Figure 2 illustrates, do the following:
1. Connect a balanced audio source (for example, a condenser microphone) to
the INPUT 1 XLR female connector.
Set the INPUT LEVEL SELECT IN 1 switch to MIC.
Set the PHANTOM 48V IN 1 switch to ON.
When using a dynamic microphone, set the PHANTOM 48V switch to OFF.
2. Connect a balanced audio source to the INPUT 2 XLR female connector.
Set the INPUT LEVEL SELECT IN 2 switch to LINE.
Set the PHANTOM 48V IN 2 switch to OFF.
3. Connect the XLR male OUTPUT connector to a balanced audio acceptor (for
example, a power amplifier with speakers).
4. Connect the 12V DC power adapter to the power socket and connect the
adapter to the mains electricity.
5. Rotate the INPUT 1, INPUT 2 and MASTER LEVEL knobs to adjust the
audio level of input 1, input 2 and of both inputs mixed together (the
MASTER LEVEL knob) to the output, respectively.
