Kramer ASPEN-32UFX User Manual

Kramer Electronics Ltd.
ASPEN-32UFX, ASPEN-1616UX, VS-8UFX – Protocol 3000
48
MATRIX-STATUS
Command Name
Permission
Transparency
Set:
-
–
–
Get:
MATRIX-STATUS?
End User
Public
Description
Syntax
Set:
–
–
Get:
Get routing status of all output
ports
#MATRIX-STATUS?␍␊
Response
Multi-line: ~nn@MATRIX-STATUS␠[ [out_signal_id,IN_signal_id],.. ]␍␊
Parameters
out_signal_id – format for identifying specific outputs: OUT.SDI.X.VIDEO.1 (X = port/output # as
written on the device panel), for example, OUT.SDI.5.VIDEO.1 (PORT/OUTPUT 5).
in_signal_id – format for identifying specific inputs: IN.SDI.X.VIDEO.1 (X = port # as written on the
device panel), for example, IN.SDI.1.VIDEO.1 (PORT/INPUT 1).
Response Triggers
Notes
In the response, each input/output pair is enclosed in square brackets “[ ]”.
For the devices with interchangeable ports, this command only shows status for those ports that are
currently defined as outputs.
Example
Get the routing status of all output ports:
#MATRIX-STATUS?<CR>
PORTS-LIST
Command Name
Permission
Transparency
Set:
–
–
–
Get:
PORTS-LIST?
End User
Public
Description
Syntax
Set:
–
–
Get:
Get the port list of this device
#PORTS-LIST?␍␊
Response
~nn@PORTS-LIST␠[port_id,..,]␍␊
Parameters
port_id – format for identifying specific ports: OUT/IN.SDI.X (X = port/input/output # as written on the
device panel), for example IN.SDI.1 (PORT/INPUT 1), OUT.SDI.5 (PORT/OUTPUT 5).
Response Triggers
Notes
The response is returned in one line and terminated with ␍␊.
The response format lists port IDs separated by commas.
This is an Extended Protocol 3000 command.
Example
Get the list of ports for this device:
#PORTS-LIST?<CR>
