ASPEN-32UFX, ASPEN-1616UX, VS-8UFX – Protocol 3000
51
Video Commands
Command
Description
GENLOCK-MODE
Set/get genlock sync mode
GENLOCK-TIME-MICROSEC
Set/get genlock delay in microseconds
VMUTE
Set/get enable/disable video on output
GENLOCK-MODE
Command Name
Permission
Transparency
Set:
GENLOCK-MODE
End User
Public
Get:
GENLOCK-MODE?
End User
Public
Description
Syntax
Set:
Set genlock sync mode
#GENLOCK-MODE␠mode␍␊
Get:
Get genlock sync mode status
#GENLOCK-MODE?␍␊
Response
Set / Get: ~nn@GENLOCK-MODE␠mode␍␊
Parameters
mode – ON, OFF (not case sensitive)
Response Triggers
Notes
This command synchronizes the routing action with sync frames. Routing does not occur until a sync
frame is detected and delay is defined in the GENLOCK-TIME-MICROSEC command.
This mode affects the whole system and is not configurable per output/input.
Examples
Set the genlock sync to ON:
#GENLOCK-MODE ON<CR>
GENLOCK-TIME-MICROSEC
Command Name
Permission
Transparency
Set:
#GENLOCK-TIME-MICROSEC
End User
Public
Get:
#GENLOCK-TIME-MICROSEC?
End User
Public
Description
Syntax
Set:
Set genlock delay in microseconds
#GENLOCK-TIME-MICROSEC␠value␍
Get:
Get genlock delay in microseconds
#GENLOCK-TIME-MICROSEC?␠value␍
Response
Set / Get: ~nn@GENLOCK-TIME-MICROSEC␠value␍␊
Parameters
value – time in microseconds, 0–99999
Response Triggers
Notes
Configures the maximum delay in microseconds between arrival of a picture frame and its routing is
executed
Examples
Set the genlock delay to 20 microseconds:
#GENLOCK-TIME-MICROSEC 20<CR>
