Kramer Galil 4-C User Manual

Galil 4-C Technical Specifications
15
15
6 Technical Specifications
Galil 4-C
Audio and Power
DESCRIPTION:
2−Way closed-back ceiling speakers
FREQUENCY RESPONSE:
85Hz to 20kHz @ -10dB
100Hz to 20kHz @ ±3dB
WOOFER:
4” (103mm) polypropylene with rubber surround
TWEETER:
0.5” (13mm) Mylar
IMPEDANCE:
8Ω (transformer tap in off position)
TRANSFORMER TAPS:
70V – 30W / 15W / 7.5W / 3.7W / Off (Lo-Z)
100V – 30W / 15W / 7.5W / Off (Lo-Z)
SENSITIVITY:
85dB SPL, 1W@1m
MAX SPL:
Continuous: 95dB
Peak: 97dB
POWER HANDLING:
30W RMS
80W continuous program
CROSSOVER FREQUENCY:
6kHz
DIRECTIVITY FACTOR (Q):
4.2, averaged 1kHz to 10kHz
DIRECTIVITY INDEX (DI):
6.2dB averaged 1kHz to 10kHz
INPUT CONNECTOR:
Terminal block
Shipping and Installation
MATERIALS:
ABS bezel, aluminum grill, metal back can
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
WEIGHT PER SINGLE SPEAKER:
1.75kg (3.9lbs) approx.
SHIPPING WEIGHT (FOR PAIR):
6.1kg (13.5lbs) approx.
DIMENSIONS:
External diameter: 19.5cm (7.68"); cutout diameter:
16.7cm (6.57")
INSTALLATION CLEARANCE:
Mounting depth: 10.7cm (4.2”)
ACCESSORIES:
Installation bracket, safety cord attached to grill,
ceiling mounting kit, cutout template
COLORS:
Available in white
Specifications are within a 10% tolerance and are subject to change without notice at
http://www.kramerelectronics.com
