Connecting the VM-1610 and VM-80A
7
6 Connecting the VM-1610 and VM-80A
Section 6.1 describes how to connect the VM-1610 and section 6.2
describes how to connect VM-80A.
6.1 Connecting the VM-1610 Distribution Amplifier
To connect the VM-1610 in a 1:10 configuration, as shown in
Figure 3, do
the following
1
1. Connect the input source (for example, a balanced stereo audio player) to
the Channel 1 INPUT terminal block connector.
:
2. Connect the OUT terminal block connectors to up to 10 acceptors (for
example, balanced stereo audio recorders).
3. Release the MODE button to the 1:10 position.
4. Switch on the VM-1610.
The audio input is distributed to the audio outputs.
Note: The Channel 2 INPUT cannot be distributed to the 10 outputs,
only the Channel 1 INPUT.
5. Adjust the right and left audio levels by turning the CH1 and CH2 LEVEL
trimmers with a small screwdriver.
To connect the VM-1610 in a 2x1:5 configuration, do the following
1
:
1. Connect input source 1 (for example, a balanced stereo audio player) to the
Channel 1 INPUT terminal block connector.
2. Connect input source 2 (for example, a balanced stereo audio player) to the
Channel 2 INPUT terminal block connector.
3. Connect the Channel 1 OUT terminal block connectors to up to 5 acceptors
(for example, balanced stereo audio recorders).
4. Connect the Channel 2 OUT terminal block connectors to up to 5 acceptors
(for example, balanced stereo audio recorders).
5. Press in the MODE button to the 2x1:5 position.
6. Switch on the VM-1610.
The Channel 1 audio inputs are distributed to the Channel 1 audio outputs.
The Channel 2 audio inputs are distributed to the Channel 2 audio outputs.
1 Switch OFF the power on each device before connecting it to your VM-1610. After connecting your VM-1610, switch on
its power and then switch on the power on each device
