Technical Specifications
13
7 Technical Specifications
Table 3 includes the technical specifications:
Table 3: Technical Specifications
1
of the VM-8H and the VM-16H
VM-8H VM-16H
INPUT: HDMI connector
OUTPUTS: 8 HDMI connectors 16 HDMI connectors
BANDWIDTH: Supports up to 2.25Gbps per graphic channel
COMPLIANCE WITH HDMI
STANDARD:
Supports HDMI and HDCP
CONTROLS: SELECT and READ buttons for selecting and storing EDID information
INDICATOR LEDs: OUTPUT STATUS 1 to 8 OUTPUT STATUS 1 to 16
OPERATING
TEMPERATURE:
0° to +55°C (32° to 131°F)
STORAGE TEMPERATURE: -45° to +72°C (-49° to 162°F)
HUMIDITY: 10% to 90%, RHL non-condensing
POWER CONSUMPTION: 100-264V AC, 50/60Hz, 28VA 100-264V AC, 50/60Hz, 48VA
DIMENSIONS: 19" x 7" x 1U W, D, H rack mountable
WEIGHT: 3.5kg (7.7lbs) approx. 4.5kg (9.9lbs) approx.
ACCESSORIES: Power cord, rack “ears”
OPTIONS: HDMI/HDMI male-to-male cables
Warning:
This is a class A product, for professional applications and environments only
1 Specifications are subject to change without notice
