4. Click COPY.
The Input 2 EDID is copied to the selected inputs.
Figure 17: EDID Management Page – EDID Copied
Once the EDID is copied, a success message appears:
Figure 18: EDID Management Page – EDID Copied Successfully
5. Click OK.
To read the EDID from the default EDID:
1. In the Navigation pane, click EDID Management. The EDID Management page appears.
2. Click Default.
3. Select the input/s (or all the inputs) to which the default EDID is copied.
4. Click Copy and follow the instructions on-screen.
