Kramer VM-2HDT Quick Start Guide

Acquire EDID by:
• Using the EDID SETUP front
panel button.
• Using the Kramer EDID Designer
PC tool connected to USB.
• Manually sending RS-232 serial
commands via laptop connected
to USB.
USB setup for RS-232 communication:
RS-232
Baud Rate:
115200
Data Bits:
8
Command Format:
ASCII
Stop Bits:
1
Parity:
None
Example (Copy the EDID data from the Output 1
to the Input):
“#CPEDID 1,1,0<cr>
Factory Reset
Protocol 3000:
#FACTORY command to reset to factory default
configuration.
VM-2HDT, VM-3HDT supports EDID Designer (via the mini USB port) that can be loaded from our Web site: Kramer
EDID Designer.
To use the mini USB port, you need to download and the Kramer USB driver from our Web site at:
www.kramerav.com/support/product_downloads.asp and install it.
Acquiring the EDID via front panel
Press EDID SETUP once to display the present EDID source: OUT 1, OUT 2, OUT 3. OUT 4, or all OUT LEDs flash (default
EDID).
To acquire an EDID:
1. Press EDID SETUP. the present EDID source is displayed.
2. Press EDID SETUP (a second time) to enter EDID select mode.
3. Press EDID SETUP repeatedly to cycle through the EDID source options.
The OUT LEDs flash in the following order:
OUT 1 -> OUT 2 -> OUT 3 -> OUT 4 -> all output LEDs flash (default EDID).
Stop pressing EDID SETUP once the required EDID source is reached.
4. Wait a few seconds, until VM-2HDT, VM-3HDT acquires the EDID.
When complete, all output LEDS return to normal operation, displaying the present output connection status.
If an unconnected output is chosen or the connected EDID cannot be read from a connected output, the VM-2HDT,
VM-3HDT loads the default EDID.
Forcing the RGB Mode
Normally (the default state), when acquiring the EDID, the device supports any color space that is defined in the acquired
EDID parameters.
To:
Do the following:
Force the acquired EDID to
support only RGB color space:
Press and hold the EDID button for few seconds until all the output LEDs
flash together four times.
Continue to acquire the desired EDID.
This acquired EDID is then forced to support the RGB color space only.
Return to the normal EDID mode:
Press and hold the EDID button for few seconds until the output LEDs
flash together once.
Continue to acquire the desired EDID.
View the current EDID mode:
Power cycle the unit.
All output LEDs will flash together once when in normal EDID mode, and
four times when in Force RGB mode.
