6 Technical Specifications
Table 3 includes the technical specifications.
Table 3: VM-30AV and VM-30AVB Technical Specifications
INPUTS:
1 composite video 1 Vpp/75: RCA connector (VM-30AV); BNC
connector (VM-30AVB)
1 stereo audio, 4.8 Vpp / 73k on RCA connectors
OUTPUTS:
3 composite video 1 Vpp/75: RCA connectors (VM-30AV); BNC
connectors (VM-30AVB)
3 stereo audio, 1 Vpp / 150 on RCA connectors
MAX. OUTPUT LEVEL: VIDEO: 2.0Vpp AUDIO: 5.4Vpp
BANDWIDTH (-3dB): VIDEO: 430MHz (-3dB),
370MHz (-0.1dB), Fully Loaded
AUDIO: >100kHz (-3dB),
20kHz (-0.1dB)
DIFF. GAIN: 0.04%
DIFF. PHASE: 0.07 Deg.
K-FACTOR: <0.05%
VIDEO NON-LINEARITY: 0.1%
S/N RATIO: VIDEO: 73.1dB AUDIO: 83dB
CROSSTALK (all hostile): VIDEO: AUDIO:
CONTROLS: Gain: video: -1.1dB to +1.8dB; audio: -66dB to +16dB; EQ.: 0 to
+14.6dB
COUPLING: AC
AUDIO THD + NOISE: 0.38% @ 1kHz
AUDIO 2nd HARMONIC: 0.02% @ 1kHz
POWER SOURCE: 12 VDC, 30mA
DIMENSIONS: 16.5cm x 12cm x 4.5cm (6.5” x 4.7” x 1.7”, W, D, H)
WEIGHT: 0.6kg (1.3lbs.) approx.
ACCESSORIES: 12 VDC power supply
OPTIONS: 19" rack adapter
