To store the selected EDID, press EDID READ as described in the
following example
1
.
To select the EDID from Output 3:
1. Press the EDID SELECT button repeatedly until OUTPUT 3 LED
lights.
2. Press the EDID READ button.
When the LED stops flashing the EDID from Output 3 is stored at the
input.
Pressing the EDID SELECT button briefly once causes the relevant LEDs
to indicate which EDID is stored at the input, as follows:
• OUTPUT 1 LED flashes—the EDID from OUTPUT 1 was the last
acquired
• OUTPUT 2 LED flashes—the EDID from OUTPUT 2 was the last
acquired, and so on
• All OUTPUT LEDs flash—the default EDID was the last acquired
• All OUTPUT LEDs flash sequentially—the Auto-Mix
2
EDID was
the last acquired
1 To cancel the EDID modification wait for a few seconds without touching any button
2 The EDID acquired is a weighted average of all the connected outputs. For example, if several displays with different
resolutions are connected to the outputs, the acquired EDID supports all the resolutions, as well as other parameters included
in the EDID
