6 Technical Specifications
Table 3 includes the technical specifications:
Table 3: Technical Specifications
1
of the VM-4HC 1:4 HDMI Distributor
INPUT: 1 HDMI connector
OUTPUTS: 4 HDMI connectors
BANDWIDTH: Supports up to 2.25Gbps bandwidth per graphic channel
COMPLIANCE WITH HDMI
STANDARD:
Supports HDMI and HDCP
CONTROLS: EDID SELECT and READ buttons
INDICATOR LEDs: POWER, OUTPUTS 1-4
POWER SOURCE: 5V DC, 1.1A
OPERATING
TEMPERATURE:
0° to +55°C (32° to 131°F)
STORAGE
TEMPERATURE:
-45° to +72°C (-49° to 162°F)
HUMIDITY: 10% to 90%, RHL non-condensing
DIMENSIONS: 21.5cm x 16.3cm x 4.4cm (8.5” x 6.4” x 1.7”) W, D, H
WEIGHT: 0.6kg (1.32lbs) approx.
ACCESSORIES: Power supply
OPTIONS: Kramer HDMI cables
2
, Rack adapter kit RK-3T
1 Specifications are subject to change without notice
2 For best results, use Kramer cables such as the C-HM/HM series, the C-HM/DM series and/or our HDMI over fiber optics
C-FOHM/FOHM series
