Technical Specifications
6
Figure 2: Connecting the VP-210K UXGA Line Amplifier
6 Technical Specifications
Table 2 includes the technical specifications:
Table 2: Technical Specifications
1
of the VP-210K UXGA Line Amplifier
INPUT:
1 UXGA on a 15-pin HD (F) connector
OUTPUT:
1 UXGA on a 15-pin HD (F) connector
1 LOOP UXGA on an 15-pin HD (F) connector
VIDEO BANDWIDTH (-3dB):
350MHz
DIFF. GAIN:
0.41%
DIFF. PHASE:
0.53°
VIDEO S/N RATIO:
66dB
K-FACTOR:
<0.05%
CONTROLS:
Level: -1.2 to +6.3dB; EQ: 0 to +4dB @50MHz
POWER SOURCE:
5V DC, 108mA
DIMENSIONS:
12cm x 7.5cm x 2.5cm (4.7” x 2.95” x 0.98”) W, D, H
WEIGHT:
0.25kg (0.55lbs) approx.
ACCESSORIES:
Power supply, mounting brackets
OPTIONS:
19" rack adapters
1 Specifications are subject to change without notice
