10
VP-472 - Operating the VP-472 SDI to HDMI Scaler
5.2.2 The Display Submenu
The Display submenu sets the display output resolution, size and aspect ratio.
The following table defines the display output parameters.
Parameter
Parameters
Factory
Default
OUTPUT
Sets the output resolution.
Native, 1920x1080p @50 (HD 1080), 1280x720p @50 (HD
720), 720x576p @50, 1920x1080p (HD 1080), 1280x720p
(HD 720), 720x480p (NTSC), 1920x1200p (WUXGA),
1600x1200 (UXGA), 1680x1050 (WSXGA+), 1400x1050
(SXGA+), 1440x900, 1280x1024 (SXGA), 1280x800
(WXGA), 1360x768, 1280x768 (WXGA), 1024x768 (XGA),
800x600 (SVGA)
PC: VGA, SVGA, XGA, 1280x800, UXGA, SXGA, WXGA,
SXGA+, WXGA+, WSXGA, WUXGA
SDTV: 480p and 576p
HDTV: 720p @50/60Hz, 1080p @50/60Hz, 1080i
@50/60Hz
1280x720
@60
SIZE
Sets the output size/aspect ratio: Full, Pan scan, Letter box,
Under 2, Under 1, Over scan
Full
EXIT
Exits the Display menu
5.2.3 The COLOR Submenu
The Color submenu sets the display output color parameters. The following table
defines the color output parameters.
Parameter
Function
Value
Range
Factory
Default
CONTRAST
Sets the output contrast
0-255
105
BRIGHTNESS
Sets the output brightness
0-192
96
R
Sets the output red value
0-255
128
G
Sets the output green value
0-255
128
B
Sets the output blue value
0-255
128
R OFFSET
Sets the output red signal level offset
0-63
32
G OFFSET
Sets the output green signal level offset
0-63
32
B OFFSET
Sets the output blue signal level offset
0-63
32
EXIT
Exits the Color submenu
