VP-505 - Operating the VP-505 3G HD-SDI to Video Scan Converter
5.2.1 The Main Menu
The following table defines the Main menu parameters and functions.
Parameter
Function
DISPLAY
Sets the output resolution, size and aspect ratio (see Section 5.2.2)
CONTRAST
Sets the output contrast; value range: 0-255, default: 105
BRIGHTNESS
Sets the output brightness; value range: 0-192, default: 96
COLOR
Sets the output color parameters (see Section 5.2.3)
SDI AUDIO
Selects which embedded audio to output: Group 1, Group 2, Group 3,
Group 4, Auto, Off (audio is not outputted) Default: Auto
When set to Auto, the unit searches for the lowest Group number which has
audio and selects this audio Group
FACTORY
RESET
Resets all parameters to factory defaults
INFORMATION
Displays current input resolution, output resolution and firmware revision
AUTO SYNC OFF
When on, this de-activates the output after a few minutes if no input is
present
When set to Auto, the unit searches for the lowest Group number which has
audio and selects this audio Group
EXIT
Exits the Main menu
5.2.2 The Display Submenu
The Display submenu sets the display output resolution, size and aspect ratio.
The following table defines the display output parameters.
Parameter
Parameters
Factory
Default
OUTPUT
PAL: 768x567i, NTSC: 720x480i
NTSC
SIZE
Sets the output size/aspect ratio: full, panscan, letterbox,
under 2, under 1, overscan
Full
EXIT
Exits the display menu
5.2.3 The Color Submenu
The Color submenu sets the display output color parameters. The following table
defines the color output parameters.
Parameter
Function
Value
Range
Factory
Default
R
Sets the output red value
0-255
128
G
Sets the output green value
0-255
128
B
Sets the output blue value
0-255
128
R OFFSET
Sets the output red signal level offset
0-63
32
G OFFSET
Sets the output green signal level offset
0-63
32
B OFFSET
Sets the output blue signal level offset
0-63
32
EXIT
Exits the Color submenu
