PT-871/2-KIT, PT-871/2xr-KIT, WP-871xr, WP-872xr, PT-871xr, PT-872xr – Defining PT-871/2-KIT, PT-
871/2xr-KIT, WP-871xr, WP-872xr, PT-871xr, PT-872xr
6
WP-871xr – Front Panel Before Assembly
Figure 7: WP-871xr Line Transmitter Wall-plate – Front Panel Before Assembly
#
Feature
Function
SETUP DIP-switches
Do not change the default DIP-switch settings (located
on the front panel, behind the frame)
6
DIP-switch 1
Must be set to ON (right).
7
DIP-switch 2
Must be set to OFF (left).
WP-872xr – Front Panel Before Assembly
Figure 8: WP-872xr Line Receiver Wall-plate – Front Panel Before Assembly
#
Feature
Function
SETUP DIP-switches
Do not change the default DIP-switch settings (located
on the front panel, behind the frame)
6
DIP-switch 2
Must be set to OFF (up).
7
DIP-switch 1
Must be set to ON (down).
