Connections and functional parts
8
10
1
5
94
6
15 16 17
2019
Description
2
3
11
12
13
18
8 Storage bin for spray gun and pipe
9 Brake
10 Fuel tank
11 Filler aperture for fuel
12 High pressure outlet
13 Hose drum (special accessories)
1 Water inlet connection with filter
2 Power cable
3 Winder for cable
4 Suction hose for detergent
5 High pressure hose
6 Spray gun
7 Spray pipe attachment
15 Master switch (appliance On- Off)
16 (Burner ON- OFF) ignition
17 Brief operating instructions
18 Manometer
19 Thermostat
20 Detergent dispensing valve
