Hose drum
with HP-hose
Receptacle
for gun
Receptacle
for lances
Put high pressure cleaner into upright
position. Remove the screw from the
brass element. Put the crank on the
hexagon and fasten with the screw.
How to assemble and furnish your high pressure cleaner
11
